Preface
The INCON-M84/M86/M86R are INCON series with CNC controller embedded system. The designed include high-density integrated circuit and eco-friendly concept, allowing the CNC controller to be small, use less power, and highly recyclable and other characteristics, it also inherited the INCON series' feature of high performance stability, reliability, and easy for maintenance. INCON-M84 is a fully closed-loop CNC controller with 4-axis simultaneous motion and 1 spindle system. The INCON-M86 is a 6-axis controller with 2 spindle systems that supports the fully closed loop 6 axis and any 4 axis simultaneous motion CNC controller. INCON-M86R not only inherits the features of INCON series controller, but also provides real-time RTCP and TWP functions with six built-in models and three types of five-axis CNC machining Programming style. INCON-M84/M86/M86R, in addition to providing standard G, M, S, T code, the controller also provides a complete compensation mechanism, and network FTP server, USB file transfer and other functions.
Functions of INCON-M84S/M86S/M86RS are the same as INCON-M84/M86/M86R, but INCON-M84S/M86S/M86RS also supports CNC TCP server function. For further information of communication protocols INCON S series controller, please refer to IClient Programming Manual. In this manual, INCON-M84/M86/M86R is used to represent INCON-M84/M86/M86R and INCON-M84S/M86S/M86RS.
In this manual, any item unique to a particular product will be marked with an icon, which is described as follows:
: M86
: M86R
: M84/M86
: M86/M86R
In addition, the user can find out the desired information within the user instructions, the CNC controller also has instant help function built-in, at any time by pressing the F1 key to display the description of the current operation items explanation. In addition, press the F2 key to enter the menu, select "Help → topic", this item provides the equivalent of the use of the operating instructions for quick-use guide. Choose "Help → Code", for a listed in the G/M instructions and simple examples. The book accompanied by a comprehensive application of the instructions, and with illustrations of various examples for reference.
Intek Technology Co., Ltd. Provide technical support in accordance to agreement, regulated by the business contract. In addition, users can download technical support documents related to this controller after registering as a member of our technical support website (http://support.intek.com.tw), or in the message board, Intek's specialists answer.
