3.12.1.6 Max G168 Speed

The Max speed for each axis can be set in this column, within G168 (RTCP) mode. The fastest speed setting for the G168 is usually below the max speed setting for the axes. This item is only provided by INCON-M86R.

Note:

"Max G168 Speed" of linear axes (X, Y, Z) should be set as the maximum speed of the axis, "Max G168 Speed" of "Rotary Axis" or "Angular Axis" (A/B, C) should regulated to meet the maximum speed of linear axes.
