3.5.9 Scaling Magnitudes


This item is used to set the effective scale of scale value (that is, the choice of three or four digits after the decimal point) and the default scale enlargement and reduction ratio of each axis in the G51 scale up/down instruction.


"Scaling Magnitudes" Dialog Box
